HEATING CABLE 20M DRAINPIPES SELF ADJUSTING

• output 500 W
• cable size 10,5 x 6 mm
• heating cable length 20 m
• connection cable length 4 m
• max. operating temperature +65°C
• cable type self-adjusting
• output 25 W/m (at +10°C) / 45 W/m (below 0°C temperatures) when melting snow and ice
• lowest installation temperature -10°C
• connection voltage 230 V
• min. bending radius 35 mm
• enclosure class: plug IP44, IP67 cable

Properties:

• Ebeco Frostvakt 25 prevents problems with icicles in gutters and damage caused by frozen drainpipes
• Frostvakt 25 has a fitted 4-metre connection cable with a plug. It can easily be connected to an earthed wall socket via an earth fault breaker
• you can use Frostvakt 25 on gutters and drainpipes to melt snow and prevent a build-up of ice, but it can also be used in other areas where cold and frost are a problem
• the heating cable cannot overheat because it is self-adjusting. And it can be crossed to fit the gutter perfectly. It gives maximum output only when needed, when there is ice and snow
• in the parts of the installation where the snow has melted and heat is no longer needed, the cable adjusts its output by up to 50%, which makes it an economical form of frost protection
• it is parallel resistive, which means that the self-adjusting heating cable consists of two parallel wires embedded in a semiconductor material that adapts its output according to the ambient temperature
• even though it may above zero outside and the frost prevention effect is not needed, the heating cable will still be turned on. To turn it off completely, you must pull out the plug or use Frostvakt Control thermostat (EB8580113), which turns the cable off in temperatures above freezing point
• Frostvakt 25 is excellent for temporary installation in gutters and drainpipes. You can easily fix it to the gutter with the aid of Ebeco Smartclip R (EB8960971 or EB8960972) and connect to a 230 V earthed socket via an earth fault breaker
• easy to remove when winter is over. For permanent installation a strain relief connector must be used and the installation must be in accordance with current electrical installation rules

Applications:

• frost protection in gutters and drainpipes
• frost protection for heat pumps
• frost protection for pipes
• frost protection of property
